Bosch SOLUTION 6000 Installation Guide

13-1
Bosch Security Systems 07/14 BLCC610I

SECTION 13
Specifications
Specifications
Electrical
Voltage Input
• 16 - 22 VAC
Current Requirement
• 22 VA min plug pack adapter or transformer
Panel Current Consumption
• 110 ma standby
Power Outputs
Continuous Power
• 1 Amp (Primary supply source only)
Secondary Source
• 5 Amp (Total with both primary and secondary source
combined)
Stand-By Battery
• 12 VDC, 7AH sealed rechargeable battery
Min Operating Voltage
• 10.2 VDC
LAN BUS
• Max total LAN length using multi strand security cable
= 300m.
• Max total LAN length using 2 pair twisted shielded data
cable (Belden 8723) = 1200m.
Telephone Connection
RJ-12 Socket or 4-way terminal.
Temperature
0
o
to 55
o
C.
Relative Humidity
5 to 85% at 30
o
C non-condensing.
Enclosure Dimensions
MW720 - 385mm (W), 260mm (H), 90mm (D)
MW730 - 385mm (W), 520mm (H), 90mm (D)
PCB Dimensions
235mm (W), 40mm (H), 85mm (D)
Warranty
3 years from date of manufacture
Approvals
♦ EN 55022:2006
♦ EN50131-3:2009 (Grade 2 - Class II)
♦ AS/NZS CISPR 22:2006
♦ EN 60950-1:2001 Amdt 11:2004
♦ AS/NZS 60950.1:2003 Amdt 1:2006
♦ AS/ACIF S002:2005
♦ PTC200 May 2006
♦ ETSI TS 103 021-1, 2 & 3
Compatible Keypads
♦ CP050B - Night Arm Station
♦ CP150B - External Vandal Resistant Keypad
♦ CP151B - External Vandal Resistant Keypad
♦ CP700B - Graphic (White)
♦ CP701B - Graphic + Prox (White)
♦ CP710B - Graphic (Black)
♦ CP711B - Graphic + Prox (Black)
♦ CP740B - Graphic Keypad With WiFi (White)
♦ CP743B - Graphic Keypad With WiFi (Black)
♦ CP722B - Graphic Keypad Smart Card Reader (White)
♦ CP732B - Graphic Keypad Smart Card Reader (Black)
♦ PR115B - External Smart Card Reader (Black)
♦ PR116B - External Smart Card Reader (White)
♦ PR113B - Internal Smart Card Reader (Black)
♦ PR114B - Internal Smart Card Reader (White)
♦ PR109B - Internal LAN Prox Reader (Black)
♦ PR110B - Internal LAN Prox Reader (White)
♦ PR111B - External LAN Prox Reader (Black)
♦ PR112B - External LAN Prox Reader (White)
Expansion Devices
♦ CM101B - Voice Module
♦ CM195B - Multi RF Receiver Interface
♦ CM401B - LAN Translator (BPT Intercom)
♦ CM704B - 8/16 Zone Input Expander
♦ CM705B - Universal Expansion Module
♦ CM707B - 8/16 Piggy Back Zone Input Expander Module
♦ CM710B - 4-Way Relay Output Module
♦ CM720B - 1 Amp Power Supply Module
♦ CM728B - Biometric Fingerprint Reader (Black)

Bosch SOLUTION 6000 Specifications

General

Partitions	8
System Type	Hybrid wired/wireless security system
Keypads	Up to 16
Communication	PSTN, optional IP module, optional GSM/GPRS module
Arming Modes	Stay, Away
Power Supply	16.5VAC
Backup Battery	12V 7Ah
Operating Temperature	0°C to +50°C
