Solution 6000
Installation Manual Input Programming
7-3
Bosch Security Systems 07/14 BLCC610I
Inputs > Commands >
Set Part 2 Zones
-
MENU 3-0-4
This menu allows you to program which zones are to be
excluded or bypassed when an area has been turned On
in Part Mode 2.
1) Enter [MENU] + [3] + [0] + [4] and use the up and
down arrows to highlight the area from the list
then press [OK].
2) Use the up and down arrow keys to select the
zone(s) that you want to disable in Part 2, then
press [OK]. Alternatively, you can enter the zone
number directly then press [OK]. Zones marked
with a tick are active and will alarm in Part 2 mode.
Zn1 Front Door
Zn2 Main Bedroom
Zn3 Lounge Window
Press OK or MENU
3) One of the following messages will be displayed
depending on the current zone programming.
4) Press [ON] to arm the zone in Part 2 mode or press
[OK] to exit.
Main Bedroom Zn2
Is not armed in PART2.
To Enable, Press ON.
To Go Back Press OK
5) Press [OFF] to disarm the zone in Part 2 mode or
press [OK] to exit.
Main Bedroom Zn2
Is armed in PART2.
To remove, Press OFF.
To Go Back Press OK
The keypad will sound an error tone when a user
attempts to disable all zones in an area for Part
Mode 2.
Zone 1 Name Zn1 is
un-bypassed. To bypass,
press ON.
Press OK or MENU
4) Press [ON] or [OFF] to toggle the zone bypass state
then press [OK] to save and exit or press [MENU] to
exit without saving.
5) Repeat steps 1 to 4 to bypass or un-bypass
additional zones.
Inputs > Commands >
Set Chime Zones
-
MENU 3-0-3
This menu allows you to program zones to be monitored
when chime mode is turned on. Chime mode is ideal for
monitoring a front door in a shop, a pool gate or other
entrance points. To sound the keypad buzzer when a
chime zone is opened (faulted). See MENU 6-1-5 —
Indicator Options. To turn on chime mode - see MENU
2-0-5 - Chime Mode On/Off.
Chime mode only works when the area is disarmed.
1) Enter [MENU] + [3] + [0] + [3] and use the up and
down arrow keys to highlight the area from the list
then press [OK].
2) Use the up and down arrow keys to highlight the
zone you want to program, then press [OK].
Alternatively, you can enter the zone number
directly then press [OK]. A tick mark displayed on
the right side of the zone name indicates that the
zone is already set for chime.
Zn1 Zone 1 Name
Zn2 Zone 2 Name
Zn3 Zone 3 Name
Press OK or MENU
One of the following messages will be displayed
depending on the current zone programming.
Zone 1 Name Zn1
Zone Chime is OFF,
To turn ON, Press ON.
To Go Back Press OK
Zone 1 Name Zn1
Zone Chime is ON.
To turn OFF, Press OFF.
To Go Back Press OK
3) Press [ON] or [OFF] to toggle the zone to be
monitored when chime mode is turned on then
press [OK] to save and exit or press [MENU] to exit
without saving.
