TECHNICAL SPECIFICATIONS
Dimensions
Printer: (x)505 x (y)388 x (z)450 mm
Print area: (x)297 x (y)210 x (z)200 mm
Box: (x)620 x (y)515 x (z)620 mm
Mechanics (general)
Powder-coated steel chassis
Toughened chrome bars for the X, Y and Z carriages
Igus bushing for X, Y and Z
Igus E-chains
Igus screw drive for the Z-axis with exible motor coupling
Powder-coated steel supports and moving parts
3-point cushioned levelling system for the print base
Quick-change print base system with neodymium magnets
Print resolution
Very high: 50 microns
High: 100 microns
Medium: 200 microns
Low: 300 microns
Mechanics (extruder)
Extruder designed in-house
0.4 mm nozzle
Blower for cooling printed objects
Print speed
Recommended: 50 mm/s
Recommended maximum: 80 mm/s
