Braun Infusomat Space Instructions For Use

41
Chapter 1
OPERATION
• Insert new lV line per Chapter 1.1. Close the pump door and open the roller clamp.
•
If prompted, prime the pump with u. Then press d to proceed when priming is
complete.
•
Connect IV line to patient and check the parameters with t.
•
Start the infusion by pressing sf.
Note: A new infusion can be started at any time during a stopped infusion. Press c
and respond yes to prompt "Exit and clear infusion". Note prompt will indicate if
PRIM, SEC or both will be cleared depending on current pump mode and infusion
status. B. Braun landing page will be displayed.
1.13 End of Infusion
• Press sf to stop the infusion. The green LED goes out. Close the roller clamp
and disconnect the line from the patient.
Remove emergency aperture cover.
Turn crank inside aperture to open the
door.
Turn crank to remove emergency
aperture cover.

Braun Infusomat Space Specifications

General

Type	Infusion Pump
Power Supply	AC/DC adapter, rechargeable battery
Display	Color graphic display
Alarms	Audible and visual alarms
Flow Rate Accuracy	±5%
Occlusion Pressure	Adjustable
VTBI Range	0.1 – 9999 ml
KVO Rate	0.1 – 5 ml/h (adjustable)
Battery	Lithium-ion
Operating Modes	Continuous
Certifications	CE, ISO 13485, IEC 60601-1
