2-4
1 Scale Hitch Bushing 250487B 1 Scale Unit Only
2 Capscrew, 1-8 UNC x 6 9390-195 1 Bushing to Frame Tube
Lockwasher, 1" 9404-041 1
Nut, 1-8 UNC 9394-020 1
3 Capscrew, 3/4-10 x 2 1/4 Gr 8 9390-146 4 Bushing to Frame Plate
Lockwasher, 3/4 9404-033 4
4 Weigh Bar -- 2 1/2" Dia. 92400 1 Scale Unit Only
5 Scale Hitch, Single Tang - 1 1/2" 250494* 1
S/N 674-B1651099 / 672-B16490099 & Lower
Scale Hitch, Single Tang - 2" 265637* 1
S/N 674-B1651100 / 672-B16490100 & Higher
6 Pin, 1 x 4 1/4" 250844 1 Replaces 250490 As
Snap Ring 91192 2 Replaces 94142 Set
7 Scale Hitch, Clevis 200004B 1 Scale Unit Only
8 Capscrew, 1-8 UNC x 7 9390-197 1
Lockwasher, 1" 9404-041 1
Nut, 1-8 UNC 9394-020 1
9 Hitch 250699* 1 Incl. 250636 & Items 26 - Repl. 250486
10 Hammer Strap Assembly (Option) 265639 1 Incl. 265638 & Items 11 - Repl. 250499
Decal, Hammer Strap 9001663 1
11 Capscrew, 3/4-10 UNC x 3 9390-149 2
Lockwasher, 3/4 9404-033 2
Nut, 3/4-10 UNC 9394-016 2
250936
• 12-19-01
ITEM DESCRIPTION PART NO. QTY. NOTES
265915
•
Black 9000913 9000533
Green 9002594 9001791
Red 9002593 9002197
Primer, Gray 9000914 9000592
Primer, White 9002595 NA
Graphite 95201 NA
PAINT GALLON SPRAY
