2-5
12 PTO Page 2-2
13 Jack Assembly, Flange Mount 232311 1 Incl. 250022 & Fasteners
Capscrew, 5/8 UNC x 1-3/4 9390-123 4
Lockwasher, 5/8 9404-029 4
Nut, 5/8 UNC Hex 9394-014 4
14 Jack, Swivel Mount - Top Wind 9003299 1 Repl. 9992B
15 Axle, 120" Rigid 200084 1
Axle, 144" Rigid 200240 1 Repl. 200085
Axle, 150" Rigid 200088 1 Req'd. for Duals
Axle, Adjustable 1 Pages 2-16 & 2-17
Brace, Axle (63 1/2" Overall) 200172 2 144 & 150" Rigid Axle only
Brace, Axle (58-1/2" Overall) 200173 2 Used with Adjustable Axle
16 Spindle Bushing, 4 1/2 x 3 3/4 x 9 1/4" 200025 2 Duals with Scale, 4 1/2" ID Axle
17
S/N 674-B1651099 & 672-B16490099 & Lower
Spindle, 2 7/8" Dia. 200176 2
Spindle, 2 7/8" Dia. - Scale 92442 2
Spindle, 4 1/2" Dia. 200177 2 For Duals
Spindle, 3 3/4" Dia. - Scale 92443 2 For Duals
17
S/N 674-B1651100& 672-B16490100 & Higher
Spindle Ass'y, 3 3/4" Dia. 250605 2 Incl. 250601, Nut,Washer,CPin
Spindle, 3 3/4" Dia. - Scale 9002009 2 Optional - See Page 2-20
18 Hub Page 2-14
19 Wheel, W10-20 x 26 - 11.25" BC 92413 2
S/N 674-B1651099 & 672-B16490099 & Lower
Wheel, W10-25 x 26 92414 2
Wheel, W10-21 x 32 92415 2
Wheel, W10-27 x 32 95960 2 Repl. 11075
Wheel, W10-20 x 34 92747 2
19 Wheel, W10-21 x 32 - 13.187" BC 92416 2
S/N 674-B1651100& 672-B16490100 & Higher
Wheel, W10-27 x 32 92417 2
19 Wheel, 16 x 38 - 13.187" BC 12397WO 4
For Dual Wheel
Wheel, 18 x 38 12398WO 4
For Dual Wheel
Wheel, 16 x 42 12399WO 4
For Dual Wheel
Wheel, 13 x 46 12967WO 4
For Dual Wheel
19 Wheel, 16 x 38 - 13.187" BC 15304 4
For Dual Wheel
Wheel, 18 x 38 15305 4
For Dual Wheel
Wheel, 16 x 42 14561 4
For Dual Wheel
Wheel, 13 x 46 15303 4
For Dual Wheel
20 Valve Stem 93300 2
21 PTO Shield 250798B 1 48 1/2" Lg.
22 U-Joint, 3/4" 92405 1
23 Pad, PTO Shield 9001496 1
24 Pad, Runner 9001497 2
25 Pin, Safety Chain, 1 1/4 x 3 3/4" 250151 1
26 Adapter Bushing 9001917 1 Optional for 1 1/2" Hitch Pin
Adapter Bushing 9002130 1 Optional for 1 3/4" Hitch Pin
27 Spacer Washer, .180 x 1.52 x 3.00 250392 1 1 1/2" Hitch Pin - Standard
28 Spacer Washer, .180 x 1.78 x 3.25 250393 1 1 3/4" Hitch Pin - Optional
Spacer Washer, .180 x 2.019 x 3.50 265389 1 2" Hitch Pin - Optional
29 Flatwasher 9405-118 1
30 Hair Pin Cotter 92424 1
31 Screen Weldment 250501 1
32 Safety Chain 9003265 1
33 Guard, PTO Shaft 251279B 1
34 Guard Pipe, PTO 251285 1 42"
ITEM DESCRIPTION PART NO. QTY. NOTES
MODEL 672 & 674 - UNDERCARRIAGE
• 12-19-01
* Specify Color as R for Red or G for Green
•
Serial No.
B19380099
& Lower
3/4" Studs
Begin Ser. #
B19380100
7/8" Studs
See Hub also
To Next Page
