HYDRAULIC PTO DRIVE
672 674
Hydraulic Drive Assembly 250086 250087 1 Includes 1 thru 24
1 Hydraulic Motor, 15.9 in.
3
9000744t 9000744 1 tRepl. 9000750-9.99 in.
3
2 Mounting Plate Weldment 230028 > 1
3 Capscrew, 1/2UNC x 10 Hex 9390-436 > 2
4 Pipe 200191 > 2
5 Base 200185 > 1
6 Shaft, Adjusting 200128 > 1
7 Header Weldment 200201 > 1
8 U-Joint Assembly 9001084 > 1 Includes Items *
U-Joint Assembly 9001043 > 1 Includes Items ^
9 Yoke, 1-1/4" Bore / 5/16" Key 9001168 > 1 *
Yoke, 1-1/4" Bore / 1/4" Key 92481 > 1 ^
Key, 5/16" 250268 > 1 *
Key, 1/4" 250265 > 1 ^
10 Cross Kit with Retaining Rings 92479 > 2 * ^
11 Yoke, 1-3/8"-21 Spline 92480 > 1 * ^
12 Capscrew, 1/2-13 UNC x 2 9390-103 > 4
13 Lockwasher, 1/2 9404-025 > 4
14 Nut, 1/2-13 UNC Hex 9394-010 > 6
15 Flatwasher, 1/2 9405-087 > 2
16 Capscrew, 1/2-13 UNC x 2-1/2 9390-105 > 1
17 Nut, Center Lock, 1/2-13 UNC 94981 > 1
18 Hose, 3/4 I.D. 9001038 > 2
19 Elbow, 45
o
Street 9001040 > 1
20 Gauge, 0-3000 psi 9001039 > 1
21 Setscrew, 1/2-13 UNC Socket Hd. 9399-106 > 2
22 Disconnect, Male 93474 > 2 7/8-14 ORB F
23 Dust Cap 91511 > 2
24 Tie Strap, 20" 9891 > 4
25 Reducer Bushing 9001882 > 2
26 Tee 9001883 > 2
27 Hose, 3/4 x 12 9001885 > 2
28 Hose, 1/2 x 15 9001886 > 2
29 Adapter, O-Ring 9001918 > 2
