brent Corner Auger - Hydraulic Drive Kit (Optional)

2-24
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
NOTES
1 5/16-12 JICM x 1 5/16-12 M-O-R
280911
HYDRAULIC DRIVE KIT (OPTIONAL)
PART NO.
280102
9004283
9004295
9004296
9004285
9001039
9004304
280066B
9004284
280069B
9390-102
9404-025
9394-010
9390-122
9405-098
9404-029
9394-014
9390-103
97618
9004399
93474
9004385
91511
9405-086
99631
DESCRIPTION
Hydraulic Drive Kit
Hydraulic Motor
Hose, 3/4" I.D. x 88"
Hose, 3/4" I.D. x 88" 90°
Run Boss Tee
Pressure Gauge
Elbow, 1/4 Male x 1/4 Female
Mount Weldment, Motor
U-joint Assembly
Plate, Bolt
HCS 1/2-13UNC x 1 3/4
Lock Washer, 1/2
Hex Nut, 1/2-13UNC
HCS, 5/8-11UNC x 1 1/2
Flat Washer, 5/8
Lock Washer, 5/8
Hex Nut, 5/8-11UNC
HCS, 1/2-13UNC x 2
Adapter
Run Boss Tee
Male Tip Coupler
Check Valve
Dust Cap
Flat Washer, 1/2
Swivel Nut Elbow, 90°
QTY.
1
1
2
2
1
1
1
1
1
1
4
6
6
2
4
2
2
2
1
1
4
1
4
4
1
•Revised 122904-2
•
•
•
•
•
•
•
•
•
•
•
•
