3-1
IMPORTANT
READ THIS BEFORE USING YOUR SCALE
THE FOLLOWING STEPS MUST BE CONSIDERED WHEN USING
YOUR SCALE AND TO REALIZE ITS BEST PERFORMANCE.
DIGI-STAR SCALES ARE MANUFACTURED TO PROVIDE 1/2%
MAXIMUM ERROR. A GOOD INSTALLATION AND PROPER USE ARE
REQUIRED IN ORDER TO OBTAIN ADVERTISED ACCURACY.
A GOOD INSTALLATION REQUIRES THAT ALL LOAD CELLS ARE
PROPERLY INSTALLED WITH "TOP" ACCURATELY POSITIONED.
OPERATION
TO INSURE 1/2% MAXIMUM ERROR, THE UNIT MUST BE USED AS
A STATIONARY LOAD-OUT WEIGH HOPPER FROM BIN TO TRUCK,
FOR EXAMPLE, THE GROUND MUST BE SMOOTH AND LEVEL WITH
MAXIMUM 5" SLOPE PER 10 FEET.
TO INSURE 1% MAXIMUM ERROR, THE UNIT MUST BE USED SO
THAT ALL WEIGHT MEASUREMENTS OCCUR ON FLAT, SMOOTH
GROUND (MAXIMUM OUT OF LEVEL 10" IN 10 FEET) IDEALLY, ALL
WEIGHT MEASUREMENTS FOR A FIELD WOULD OCCUR IN THE
SAME SPOT.
WARNING!
ALWAYS DISCONNECT CABLES FROM SCALE
INDICATOR BEFORE JUMP STARTING ENGINE
+
+
+
SCALE KIT LAYOUT & INSTALLATION................................................... 3-2
SCALE MODEL 150
OPERATION .......................................................................................... 3-4
INSTALLATION REQUIREMENTS ......................................................... 3-6
SHORT-FORM SET-UP/CALIBRATION ................................................... 3-7
CHANGE LBS TO KGS ......................................................................... 3-9
CHANGE UPPER RANGE ....................................................................3-10
DOWNLOADER MODULE .....................................................................3-11
TROUBLESHOOTING GUIDE ...............................................................3-12
SECTION III - SCALE
• 04-01-02
