2-14
Spindle 2 7/8" 4 1/2" 3 3/4" 3 3/4"
Bolt Circle 11.25" 13.187" 13.187" 13.187"
Serial No. & Lower Singles Duals Duals
674 #B1651099 / 672 #B1649099 Std, Scale Standard Scale
Beginning Ser. No. Singles Duals§ §
Begin S/N B19380100
674 #B1651100 / 672 #B1649100 Std,Scale Std,Scale
See Page 2-15
Complete Hub Assy 200036 200144 200079 200145* 1 Incl. 1-6 &10-13
1 Seal, 2 7/8" ID 92456 - - - 1 28464TA
Seal, 4 3/8" ID - 92455 - - 1 43605SA
Seal, 3 11/16" ID - - 92565 92565 1 37605SA
2 Stud, 3/4-16 x 3 / 3 1/2 Gr 8 94794 93333 94794 93333 10
3 Nut, 3/4-16 UNF,Flange / Hex 92458 93334 92458 93334 10
Nut, 3/4-16 UNF Jam - 9395-015 - 9395-015 5 Inner Dual Wheel
4 Outer Cup 92461 92462 > > 1 453A / HM212011
5 Outer Bearing Cone 92463 92464 > > 1 460 / HM212049
6 Hub Cap 92466 92465 > > 1
7 Cotter Key, 3/8 x 4" 9391-062 9391-091 > > 1
8 Nut 9393-024 92470 > > 1
9 Washer 92471 92472 > > 1
10 Capscrew, 5/16-18 x 1/2 9390-026 > > > 4
11 Hub 200037* 250329* 200039* 250329* 1 Incl. Items 2,4,12
12 Inner Cup 92475 92476 > > 1 33462 / HM218210
13 Inner Bearing Cone 92546 92545 > > 1 33275 / HM218248
14 Flatwasher - 93335 - 93335 10 Dual Wheels
ITEM DESCRIPTION PART NO.
QTY.
NOTES
MODELS 672 & 674 HUB
* Specify Color as R for Red or G for Green
• 12-19-01
200144
•
To Next Page
