2-15
MODELS 672 & 674 - HUB - DUAL WHEELS
Begin Ser. No. B19380100
266929
Hub Assembly--3 3/4" Spindle 266456*
Includes Items 1 thru 8
1 Seal 92565 1 Ref. No. SA370605
2 Outer Cup 92462 1 HM212011
3 Outer Bearing Cone 92464 1 HM212049
4 Hub Cap 92465 1
5 Bolt 9390-026 4
6 Hub w/Cups & Studs 266455 1 Incl. Items 2 & 7
7 Inner Cup 92476 1 HM218210
8 Inner Bearing Cone 92545 1 HM218248
9 Cotter Key, 3/8 x 4 9391-090 1
10 Nut 92470 1
11 Washer 92472 1
12 Ring 14442 1
13 Bolt, 7/8-14 UNF x 4 97043 10
14 Lockwasher, 7/8 9404-037 10
15 Locator Bolt, 7/8-14 x 4 3/4 266459 1
ITEM DESCRIPTION PART NO. QTY. NOTES
* Specify Color as R for Red or G for Green
• 12-19-01
