2-18
Gear Box, Complete 9002812 1 Incl. Items 1-17 (Repl. 9000918)
1 Shaft, Input 9001131 1 1.8:1 Gear
2 Shaft, Output 9001132 1 1.8:1 Gear
3 Bearing Cone 92697 1 Large
4 Bearing Cup 92698 1 Large
5 Bearing Cone 9001133 2
6 Bearing Cup 9001134 2
7 Bearing Cone 9001135 1 Small
8 Bearing Cup 9001136 1 Small
9 Casting w/Tapped Holes 9003447 1 (Repl. 9001137)
10 Casting w/Thru Holes 9003448 1 * (Repl. 9001138)
11 Seal 92688 1 Small
12 Seal 92702 1 Large
13 Capscrew, 3/8-16 UNC x 1-1/2 9390-057 9 *
14 Bushing, Vented 95282 1 *
15 Pressure Relief, 5-PSI 92352 1 *
16 Plug, Plain 92350 3 *
17 Plug, 3/4" NPT 9001139 1 *
45
o
GEAR BOX
*Not Shown
ITEM DESCRIPTION PART NO. QTY. NOTES
9000918
• 09-04-01
•
•
