1 Upper Auger 250416 265130 1
2 Upper Auger Housing ×250652* 250013* 1 ×Includes Items 4 & 5A
3 Flange Bearing, 1-1/2 4-Hole 92406 > 1
Washer 9001197 > AR 2 x 1.554 x .134
4 Capscrew, 1/2-13 UNC x 5-1/2 9390-114 > 4
Locknut, 1/2-13 UNC 94981 > 4
5 Spring, Auger, 1 x 3" 92407 > 4
672-B1681099 / 674-B1682099 & Lower
5A Spring, Auger, 1 x 4" 9001812 > 4
672-B1681100 / 674-B1682100 & Higher
6 Machine Screw, 5/16-18 UNC x 2 95572 > 1 Rd Slot Hd-Stub Shaft Retainer
Nut, 5/16-18 UNC 9394-004 > 1
7 Hydraulic Hose, 228" O-Ring Ftg. 9002215 > 2
Repl. 95140 (pipe thd), Requires12
8 Bulkhead Fitting 95192 > 2
9 Hydraulic Cylinder, 36" Page 2-16 > 1
10 Hydraulic Hose, 16" 95141 > 1
11 Hydraulic Hose, 40" Lg. 95003 > 1
12 Disconnect Male Tip - SAE O -Ring 91383 > 4
Repl. 93474 (pipe thd) - For 7 &19
13 Pin, Inside Cylinder, 1 x 4" 250104 > 2/1
Pin, Inside Cylinder, 1 x 5 1/2" 92428 0/1
Top Pin, 2 1/2 x 36" Cylinder only
14 Hair Pin, #6 92424 > 4
15 Rod, Door Indicator 250590 > 1
16 Capscrew, 1/2 UNC x 1 9390-099 > 1
Lockwasher, 1/2 9404-025 > 1
17 Tie Strap, 15 1/2" 9000107 > 6
18 Hose Bracket 7-0043B > 1
19 Hydraulic Hose, 216" O-Ring Ftg. 9002212 > 2
Repl. 92426 (pipe thd), Requires12
20 Hydraulic Cylinder, 14" Page 2-16 > 1
21 Upper Pin, Cylinder, 1 x 2-7/8 233760 92425 1 1 x 3"
22 Lower Pin, Cylinder, 1 x 3-1/2 804572 92425 1 1 x 3"
23 Hair Pin, #6 92424 > 8
24 Hinge Pin 200012 250014 1 1 x 16 1/2 1 x 20-7/8
25 Keeper, Shaft 7-0328 > 1
26 Capscrew, 1/2 UNC x 1 9390-099 > 1
Lockwasher, 1/2 9404-025 > 1
Nut, 1/2-13 UNC Hex 9394-010 > 1
27 Arm, Cylinder 200033 250474 1
28 Rockshaft & Crank Ass'y 200034 250016 1
29 Tee Bar, Yoke End 200028B > 1
30 T-Bar, Threaded 200013 > 1
31 Pin, Upper T-Bar 250106 > 1
32 Pin, Lower T-Bar 250105 > 1
33 Nut, 1-8 Jam 94740 > 2
34 Restrictor, .030" 95193 > 2 Repl. 9000288
35 Chute Kit, Incl. Items 36 thru 44 250317 265318
36 Shroud, Outlet 250457B 265182B 1
37 Strap 250432B 250428B 2
38 Chute 9001437 9001438 1
39 Trim Lock 9000787-15 9000787-24 1
40 Trim Lock 92444-17 92444-30 1
41 Fender Washer, 1/4 x 2 94763 > 6
42 Capscrew, 1/4-20 UNC x 1 9390-005 > 20
43 Fender Washer 9405-066 > 25
44 Locknut, 1/4-20 UNC Centerlock 9936 > 20
45 Adjustable Chute 9001780 > 1 Option
ITEM DESCRIPTION PART NO. PART NO. QTY. NOTES
MODEL 672 & 674 - AUGER
672
674
• 12-19-01
•
•
* Specify Color as R for Red or G for Green
•
•
