3-14

Confidential

9. DISASSEMBLY PROCEDURE

9.1 Preparation

 Disconnecting Cables and Removing Accessories

Prior to proceeding with the disassembly procedure,

(1) Disconnect the following:

• USB cable (if connected)

• LAN cable (if connected)

(2) Remove the following:

• Paper tray

• Toner cartridge and drum unit

• Duplex tray

• LAN port cap

Fig. 3-8

Toner cartridge and drum unit

Duplex tray

LAN port cap

USB cable

LAN cable

Paper tray
