5-22
Confidential
1.3.12 Print frame pattern (single-side printing) (function code: 69)
<Function>
This function is used to print the frame pattern on a single side of the paper to check for
printing flaws and omission.
<Operating Procedure>
(1) Set the paper specified in the default paper settings (A4 or Letter) to the paper tray.
(2) Press the [▲] or [▼] key in the initial state of maintenance mode to display
"MAINTENANCE 69" on the LCD, and press the [OK] key. "PRINTING" is displayed on
the LCD, and the frame pattern (refer to the figure below) is printed on a single side of
the paper.
(3) When printing is completed, "WAKU SX" is displayed on the LCD.
When you press and hold the [Go] key, this operation is finished and the machine
returns to the initial state of maintenance mode.
Frame pattern
Fig. 5-7
Note:
• If printing fails, printing is stopped with displaying any of the errors shown in the table
below. To retry printing, refer to the "Remedy" in the table below to eliminate the error
cause, and press the [Go] key. "PRINTING" is displayed on the LCD, and the frame
pattern is printed on a single sheet of paper.
Error display Remedy
Replace Toner Replace the toner cartridge and press the [Go] key to release the
error.
Cover is Open Close the front cover.
No Paper Refill the paper tray and close it. And then press the [Go] key to
release the error.
Jam Tray1 Remove the jammed paper, close the paper tray and all covers,
and press the [Go] key to release the error.
Jam Rear
