1.3.14 Print test pattern (function code: 71)

This function is used to print the test pattern to check whether the develop roller or exposure

drum is dirty or damaged.

(1) Press the [▲] or [▼] key in the initial state of maintenance mode to display

"MAINTENANCE 71" on the LCD, and press the [OK] key. "SELECT: A4" is displayed on

the LCD.

(2) Refer to the <Paper size> table, press the [▲] or [▼] key to select the paper size, and

press the [OK] key. "SELECT: PLAIN" is displayed on the LCD.

(3) Refer to the <Print specification> table, press the [▲] or [▼] key to select the media

specification, and press the [OK] key. "SELECT: SX" is displayed on the LCD.

(4) Refer to the <Print type> table, press the [▲] or [▼] key to select the print type, and

press the [OK] key. "SELECT: 1PAGE" is displayed on the LCD.

(5) Refer to the <Print page> table, press the [▲] or [▼] key to select the pages printing,

and press the [OK] key. "PRINTING" is displayed on the LCD, and printing test pattern

starts using the selected conditions.

(6) When printing is completed, "2D3S K" is displayed on the LCD, and it returns to the

printing pattern display. Press the [OK] key to perform this again.

(7) Press and hold the [Go] key, and the machine returns to the initial state of maintenance

mode.

Note:

• If printing fails, printing is stopped with displaying any of the errors shown in the <Error

display> table. To retry printing, refer to the "Remedy" in the table to eliminate the error

cause, and press the [Go] key. "PRINTING" is displayed on the LCD, and the test

pattern is printed.

LCD Description

SELECT:A4 A4

SELECT:ISOB5 ISO B5

SELECT:JISB5 JIS B5

SELECT:A5 A5

SELECT:A5L A5L

SELECT:JISB6 JIS B6

SELECT:A6 A6

SELECT:EXECUTE Executive size

SELECT:LEGAL Legal size

SELECT:FOLIO Folio size

SELECT:HAGAKI Postcard size

SELECT:LETTER Letter
