Brother HL-2560DN Service Manual

2-9
Confidential
3. ERROR INDICATIONS
This machine includes a self-diagnosis function. If the machine does not work normally it
judges that an error has occurred, and indicates the corresponding error message on the
LCD, which in turn helps the service personnel to quickly find out the problem.
3.1 Error Codes
Errors in shaded column do not usually occur during normal use. The possible causes are
noise around the installation site, fluctuation of the power supply voltage, and failures in the
software.
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
0100 ― 0504
After the heat unit was heated normally, the
center thermistor of the fuser unit detected a
temperature lower than the specified value.
2-28
0201
Cannot detect the synchronized signal
of the main motor.
The speed of the main motor does not
stabilize within the specified time.
2-26 0505
The center thermistor of the fuser unit
detected a temperature rise greater
than the specified value within the
specified time.
2-28
0202 ― 0506
The center thermistor of the fuser unit
detected a temperature fall greater than the
specified value within the specified time.
2-29
0203 ― 050A
The hardware detected a temperature
error through the center thermistor or
the side thermistor of the fuser unit.
2-30
0204 ― 050B
When the center thermistor of the fuser unit
was lower than the idle temperature, the side
thermistor detected a temperature higher
than the specified temperature.
2-30
0205 ― 050C
When the center thermistor of the fuser unit
was higher than the idle temperature, the
side thermistor detected a temperature lower
than the specified temperature.
2-30
0206 ― 050D ―
0207 ― 050F An error occurred in the fuser unit. 2-30
0208 ― 0600
A communication error occurred
between the ASIC controlled by
engine and the motor driver.
2-31
0209 ― 0700 ―
0300
Cannot detect the lock signal of the polygon
motor for the laser unit (second time).
2-27 0800 ―
0305
Cannot detect the lock signal of the polygon
motor for the laser unit (first time).
2-27 0900
Detected irregular power supply for
more than 100 times.
2-31
0401
Cannot detect the synchronized signal
of the polygon motor for the laser unit
(second time).
2-27
0A01 ―
0402 ― 0A02 Detected a fan failure. 2-32
0405
Cannot detect the synchronized signal of the
polygon motor for the laser unit (first time).
2-27 0B01
An error occurred in the high-voltage
power supply PCB ASSY while operating.
2-32
0501
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time.
2-28 0B02
An error occurred in the high-voltage
power supply PCB ASSY when the
machine was in the ready state.
2-32
0502
The center thermistor of the fuser unit has
not reached the specified temperature
within the specified time after it was
heated normally to the certain level.
2-28 0C00 ―
0503
The center thermistor of the fuser unit
detected a temperature higher than
the specified value.
2-28 0D01 ―
