 Error code 8A01
The registration rear sensor detected that the paper fed was smaller or larger than the
specified size in duplex printing mode.
 Error code 8C00
There is no paper set in the manual feed slot on the manual feed slot fix mode.
Size Error DX
Specify the correct paper.
<User Check>
• Use appropriate paper (Letter to Legal).
Step Cause Remedy
1
Registration rear actuator
caught in some sections of the
machine
Reattach the registration rear actuator.
2
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
3
Main PCB failure Replace the main PCB ASSY.
Manual Feed
Load paper.
<User Check>
• Set paper in the manual feed slot.
Step Cause Remedy
1
Registration front actuator
caught in some sections of the
machine
Reattach the registration front actuator.
2
Connection failure of the
registration rear sensor harness
Reconnect the registration front/rear sensor
PCB harness.
3
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
4
HVPS flat cable breakage Replace the HVPS flat cable.
5
Registration rear sensor failure Replace the registration front/rear actuator
holder ASSY.
6
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
7
Main PCB failure Replace the main PCB ASSY.
