Brother MFC-8370DN Service Manual

3-63
Confidential
6. SOFTWARE SETTING PROBLEMS
The machine may not print the data correctly if there are incorrect software settings.
<User Check>
- Check that the parallel cable, USB cable and the network cable is not damaged or
broken.
- Check that the correct machine is selected if you have an interface switching device.
- Check the descriptions on the software setting in the user’s guide.
- Try resetting the factory settings. (Refer to Users guide.)
Step Cause Check
Result Remedy
1
Failure inside the
machine
Does the machine print
“Printer Settings” ?
("4.21 Display of the
Machine’s Log
Information (Function
code 80)" in Chapter 7.)
No
Identify the error type, and
then refer to the specified
section of this chapter.
2
Machine
connection
For Macintosh, has the
product ID been
verified?
No
Verify the product
ID.Product ID:
DCP8070D 021Bh
DCP8080DN 0218h
DCP8085DN 021Fh
MFC8370DN 021Ah
MFC8380DN 0219h
MFC8480DN 0217h
MFC8880DN 0216h
MFC8890DW 0215h
3
USB host relay
PCB failure
Is the problem solved
after replacing the USB
host relay PCB ASSY?
Yes
Replace the USB host
relay PCB ASSY.
4
Main PCB failure Is the problem solved
after replacing the main
PCB ASSY?
Yes
Replace the main PCB
ASSY.

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
