4.4 ADF Performance Test (Function code 08)
<Function>
The machine counts the documents fed by the automatic document feeder (ADF) and
displays the count on the LCD for checking the ADF performance.
<Operating Procedure>
(1) Set documents. (Allowable up to the ADF capacity.)
The "DOC. READY" will appear on the LCD.
(2) Press the [0] and [8] keys in this order.
MFC-8380DN/8880DN/8890DW only
Press the [ ] or [ ] buttons so that the "[ ]: DX, [ ]: SX" is displayed on the LCD.
While counting the documents, the machine feeds them in and out, displaying the
current count on the LCD as shown below.
(3) Press the [Stop/Exit] button, then the operation of the above will finish and return the
machine to the initial stage of the maintenance mode.
ADF CHECK P.01
Current count (1st page in this example)
To Next Page
