9. DISASSEMBLY PROCEDURE
■ Preparation
Prior to proceeding with the disassembly procedure,
(1) Unplug
• the AC cord,
• the USB cable, if connected,
• the LAN cable, if connected.
(2) Remove
• the Paper tray,
• the Toner cartridge and Drum unit,
• the Duplex unit.
Fig. 5-8
Note:
• The figures are described as the CCD models if the procedure is the same with the CIS
models.
Duplex unit
Paper tray
Drum/toner ASSY
AC cord
USB I/F cable
LAN cable
