Brother MFC-8370DN - Panel Unit; CCD Model

5-143
Confidential
9.11 Panel Unit
■ CCD model
9.11.1 Panel Unit
(1) Disconnect the connector of the Panel PCB harness from the Main PCB.
Fig. 5-165
Note:
• In the case of the CIS model, refer to "9.11.5 Panel Unit" to "9.11.9 Scanner Dress
Cover L/R".
Main PCB
<Left side>
Main PCB
Panel PCB harness
