9.14 Driver PCB
■ CCD model
9.14.1 Driver PCB
(1) Disconnect the connector of the Driver harness from the Main PCB.
Fig. 5-192
Note:
• In the case of the CIS model, refer to "9.14.2 Driver PCB".
Driver PCB
Driver harness
Main PCB
Main PCB
