Brother MFC-8370DN Service Manual

5-7
Confidential
CIS
model
ADF chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF FG harness Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
ADF relay PCB ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Motor frame ASSY
Taptite cup S M3x6 SR 3 0.7±0.05 (7±0.5)
Taptite cup S M3x10 1 0.7±0.05 (7±0.5)
Pickup solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
ADF motor
Screw pan (S/P
washer) M3x6 DB
2 0.7±0.1 (7±1)
Exit solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Lower document chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Separate roller holder ASSY Taptite cup B M3x10 1 0.8±0.1 (8±1)
Support plate Taptite cup B M3x6 3 0.5±0.1 (5±1)
Document exit tray sensor
cover ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Document exit tray roller holder
ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Upper document sub chute Taptite cup B M3x10 2 0.5±0.1 (5±1)
Gear 34 Taptite cup B M3x10 1 0.5±0.1 (5±1)
Exit chute Taptite bind B M4x10 1 0.7±0.05 (7±0.5)
CCD
model
Document scanner unit Taptite cup B M4x20 2 0.8±0.1 (8±1)
Scanner top cover ASSY Taptite cup B M4x12 6 0.8±0.1 (8±1)
Lock lever B Taptite B M3x6 1 0.4±0.05 (4±0.5)
Lock lever A Taptite B M3x6 2 0.4±0.05 (4±0.5)
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
Drive plate ASSY Taptite B M3x8 4 0.5±0.1 (5±1)
Scanner motor FB
Screw, pan (S/P
washer) M3X6
2 0.7±0.1 (7±1)
Pulley ASSY Taptite B M3x6 2 0.4±0.05 (4±0.5)
CIS
model
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
CCD
model
Panel unit ASSY Taptite cup B M4x12 4 0.7±0.1 (7±1)
Panel bottom cover Taptite cup B M3x10 4 0.5±0.1 (5±1)
NCU FG harness ASSY
Screw, pan (S/P
washer) M3.5X6 SR
1 0.4±0.05 (4±0.5)
NCU shield plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
NCU shield cover
Screw, pan (S/P
washer) M3.5X6
1 0.4±0.05 (4±0.5)
NCU PCB ASSY Taptite cup S M3x6 2 0.5±0.05 (5±0.5)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
