Brother MFC-8370DN Service Manual

5-9
Confidential
CCD
model
CIS
model
Main PCB
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
Screw pan M3x6 2 0.5±0.1 (5±1)
Gear plate calking ASSY
Taptite bind B M4x12 8 0.9±0.05 (9±0.5)
Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
Main motor ASSY Taptite cup S M3x6 4 0.7±0.1 (7±1)
Plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
Main shield plate ASSY
Taptite bind B M4x12 3 0.9±0.1 (9±1)
Taptite cup S M3x6 1 0.7±0.1 (7±1)
MP solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Spring Taptite cup B M3x8 1 0.4±0.1 (4±1)
T1 solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Register solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Ejector solenoid Taptite bind B M3x10 1 0.5±0.1 (5±1)
New toner actuator Taptite cup B M2x6 1
0.13±0.03
(1.3±0.3)
Laser scanner unit Taptite cup S M3x6 5 0.7±0.1 (7±1)
LVPS PCB unit terminal
Screw, pan (S/P
washer) M3.5X6 SR
1 0.5±0.05 (5±0.5)
Base plate LV Taptite bind B M4x12 5 0.8±0.1 (8±1)
NCU FG harness
Screw, pan (S/P
washer) M3.5X6 SR
1 0.5±0.05 (5±0.5)
LV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
SW holder ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
Safety louver Taptite bind B M3x10 1 0.5±0.1 (5±1)
Base plate HV Taptite bind B M4x12 4 0.8±0.1 (8±1)
HV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
High-voltage PS PCB ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
Toner LED PCB unit ASSY Taptite pan B M3x8 1 0.5±0.1 (5±1)
Frame L Taptite bind B M4x12 4 0.8±0.1 (8±1)
(Under bar) Taptite bind B M4x12 2 0.7±0.1 (7±1)
MP feed frame Taptite bind B M3x8 2 0.5±0.1 (5±1)
MP PE sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
Feed frame Taptite bind B M4x12 2 0.7±0.1 (7±1)
PE EG sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
