Brother MFC-8370DN Service Manual

5-15
Confidential
■ Gear name
1 LM5016001 EJECTOR GEAR 16 15 LM5065001 MP GEAR 55/60 SECTOR
2 LJ7365001 IDLE GEAR 16B 16 LM5104001 GEAR 17 (white)
3 LM5016001 EJECTOR GEAR 16 17 LM5057001 FEEDER GEAR 48
4 LM5013001 EJECT GEAR 28 SECTOR 18 LM5050001 DX GEAR 27/68 L
5 LM5019001 EJECTOR GEAR 22 19 LM5460001 P/P DIFFERENTIAL
6 LM5048001 FUSER GEAR 39R H/R DRIVE 20 LM5025001 P/P GEAR 17 CENTER
7 LM5042001 FUSER GEAR 17/63R PENDULUM 21 LM5026001 P/P GEAR 32CARRIER
8 LM5052001 REGISTER GEAR 21 CENTER 22 LM5027001 P/P GEAR 15 PLANETARY
9 LM5053001 REGISTER GEAR 48 CARRIER 23 LM5028001 P/P GEAR 147/37 INTERNAL
10 LM5055001 REGISTER GEAR 159/43 INTERNAL 24 LM5023001 P/P GEAR 29 CLUTCH CAM
11 LM5054001 REGISTOR GEAR 19 PLANETARY 25 LM5070001 T1 GEAR 31/47
12 LM5101001 GEAR 23 26 LU7020001 T1 GEAR 50/45 SECTOR
13 LM5461001 REGISTER DIFFERENTIAL 27 LM5103001 GEAR 20
14 LM5056001 FEEDER GEAR 21/31 PENDULUM 28 LM5102001 GEAR 17 (black)

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
