<WSW20> (Overseas communications mode setting)
* EP: Echo protection
• Selector 1: EP tone prefix
Setting this selector to "1" makes the machine transmit a 1700 Hz echo protection (EP)
tone immediately preceding training in V.29 modulation system to prevent omission of
training signals.
Prefixing an EP tone is useful when the machine fails to transmit at the V.29 modem speed
and always has to fall back to 4800 bps transmission.
The setting made by this selector takes effect only when the Overseas Mode is set to ON.
• Selectors 2 and 3: Overseas communications mode
These selectors should be used if the machine malfunctions in overseas communications.
According to the communications error state, select the signal specifications.
Setting selector 2 to "1" allows the machine to use 1100 Hz CED signal instead of 2100 Hz
in receiving operation. This prevents malfunctions resulting from echoes, since the 1100
Hz signal does not disable the echo suppressor (ES) while the 2100 Hz signal does.
Setting selector 3 to "1" allows the machine to ignore a DIS signal sent from the called
station once in sending operation. This operation suppresses echoes since the first DIS
signal immediately follows a 2100 Hz CED (which disables the ES) so that it is likely to be
affected by echoes in the disabled ES state. However, such a disabled ES state will be
removed soon so that the second and the following DIS signals are not susceptible to data
distortion due to echoes. Note that some models when called may cause error by receiving
a self-outputted DIS.
The setting made by selector 3 takes effect only when the Overseas Communications
Mode is set to ON. (The setting made by selector 2 is always effective.)
• Selectors 8: Limitation on CNG detection
If this selector is set to "1," the machine detects a CNG signal according to the condition
preset by selectors 2 and 3 on WSW18 after a line is connected. If it is set to "0," the
machine detects a CNG signal as long as the line is connected.
Selector No. Function Setting and Specifications
1 EP* tone prefix 0: OFF 1: ON
2
Overseas communications
mode (Reception)
0: 2100 Hz 1: 1100 Hz
3
Overseas communications
mode (Transmission)
0: OFF 1: Ignores DIS once.
4
5
Min. time length from reception
of CFR to start of transmission
of video signals
No. 4 5
0 0: 100 ms
0 1: 200 ms
1 0: 300 ms
1 1: 400 ms
6
7
At CNG detection, elimination of
chattering noise (Not used.)
8 Limitation on CNG detection 0: OFF 1: ON
To Next Page
