App. 1-37
Confidential
• Selectors 6 through 8:Extension of incoming calling signal (CI) frequency band
specified by selectors 1 through 4 on WSW14
At the start of reception, if the machine detects the frequency of a CI signal specified by
selectors 1 through 4 on WSW14, it starts the ringer sounding. However, the machine may
fail to detect the CI signal normally due to noise superimposed at the time of reception. To
prevent it, use selectors 6 through 8 on WSW36.
If the machine detects higher frequencies than the setting made here, it regards them as
noise and interprets the detecting state as being normal, allowing the ringer to keep
sounding according to the preset number of ringers (until it starts automatic reception of
FAX data in the FAX mode or enters the TAD mode in the TEL mode).
<WSW37> (Function setting 15)
• Selector 1:
Printout of the stored image data of an unsent document onto an error report
This selector determines whether or not to print out the 1st-page image data of a document
onto the error report if the document image data stored in the temporary memory cannot be
transmitted normally.
• Selector 2: Erasure of the stored image data of an unsent document at the time of the
subsequent in-memory message transmission
If in-memory message transmission fails repeatedly when selector 1 is set to "1," the
temporary memory will be occupied with image data. Setting selector 2 to "1" will
automatically erase the stored 1st-page image data of an unsent document at the time of
the subsequent in-memory message transmission only when recording paper or toner runs
out.
Selector No. Function Setting and Specifications
1
Printout of the stored image
data of an unsent document
onto an error report
0: No 1: Yes
2
Erasure of the stored image
data of an unsent document at
the time of the subsequent in-
memory message transmission
0: No 1: Yes
3
I
8
Not used.
To Next Page
