• Selectors 5 and 6 / 7 and 8:Selection of judging function for scanning pages
compensation
These selectors set the condition to control scanning pages compensation. Some
operation losses occur in the control of the compensation. If you want to start scanning
immediately even if the image quality is not good, set to "01: Not discriminates". If you want
to give priority to the image quality even though losses are increased, select one of others
("00: Discriminates depending on the rate of change" or "10: Discriminates every page").
<WSW63> (Function setting 25)
• Selector 3: Clock type
Setting this selector to "1"displays Japanese clock type (YMD). If this selector sets to "0",
select USA type (MDY) or European type (DMY) by WSW17 selector 5.
• Selector 4: Demo print type (Demo language)
This selector specifies the language for Demo print.
• Selector 8: Font support for Israel
To enable the font support for Israel, set this selector to "1".
Selector No. Function Setting and Specifications
1
2
Not used
3 Clock type
0 : Follow to WSW17
1 : Japanese Type (YMD)
4
I
7
Demo print type
(Demo language)
0000 : Other
0001 : English
0010 : USA
0011 : CANADA
0100 : JAPANESE
0101 : EU1
0110 : EU2
0111 : EU3
1000 : EU4
1001-1111 : Reserved
8 Font support for Israel 0: Disable 1: Enable

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
