Brother MFC-9440CN - Page 142

Confidential
3-10
PG2
PG2: PG-661(W) (2mm dia. ball)
BG2
BG2: BG-MS (2mm dia. ball)
GE2
GE2: GE-676 (2mm dia. ball)
F roller shaft LT
F roller shaft LT
LT frame R
LT frame L
F roller shaft LT
F roller shaft LT
2 places
2 places
LT frame L
In case of
2mm dia. ball x4
28 places (4 place x7)
