Brother MFC-9440CN - Front Door Sub

Confidential
3-107
8.30 Front Door Sub
(1) Remove the five cup B M4x10 Taptite screws and one cup B M3x8 Taptite screw, and then
remove the Front door sub.
Fig. 3-142
Taptite, cup B M3x8
Taptite, cup B M4x10
Taptite, cup B M4x10
Front door sub
Front door unit ASSY
<Left side>
Taptite, cup B M4x10
