Confidential
3-110
(4) Remove the Front cover release button and Button spring from the Hook cover.
Fig. 3-147
(5) Release the two Hooks to remove the Front door Main from the Front door unit ASSY.
Fig. 3-148
Hook cover
Front cover release button
Button spring
Front door unit ASSY
Hooks
Front door main
<Right side>
<Left side>
Front cover release button
Button spring
Hooked
Hooked
