3-14
Confidential
6
Power supply shield unit: Power supply harness
(3_084L)
Power supply PCB
Power cord
Power supply harness
Power supply shield
PS PCB insulator
Lower power
supply frame
[200V]
[100V]
(3_085L)
Power supply shield
Power supply PCB
Cable guide
Power cord
Ferrite core
Cable guide
Power supply harness
[200V]
Ferrite core
FG wire
