Brother MFC640CW - User-Access to the Maintenance Mode

8-3 Confidential
8.3 USER-ACCESS TO THE MAINTENANCE
MODE
Basically, the maintenance-mode functions listed on the previous page should be accessed by
service personnel only. However, you can allow end users to access some of these under the
guidance of service personnel (e.g., by telephone).
The user-accessible functions (codes 10, 11, 12, 53, 66, 75, 76, 80, 82, 87, and 91) are shaded
in
the table given on the previous page. Function code 10 accesses the firmware switches, each of
which has eight selectors. You should not allow end users to access all of those selectors, but you
can allow them to access user-accessible selectors which are shaded
in the firmware switch tables
in Appendix 4.
The service personnel should instruct end users to follow the procedure given below.
MFC820CW/640CW
(Key names enclosed in parentheses apply to the MFC820CW.)
(1) Press the Menu/Set (Menu), Black Start, Menu/Set (Menu), and Black Start keys in this
order.
TIP: For the FAX models equipped with numerical keypads, you may press the Menu/Set,
Black Start, and 0 keys instead in the same way as conventional models.
The "MAINTENANCE 10" appears on the LCD.
(2) To access function code 10, press the Menu/Set (OK) key.
To access any other function code, call up the desired code using the
and keys or
numerical keys.
Then press the Menu/Set (OK) key.
For function code 10, access the desired firmware switch according to the operating procedure
described in Appendix 4.
(3) To switch the machine back to the standby state, press the Stop/Exit key. When each of the
user-accessible functions is completed, the machine automatically returns to the standby state.
MFC820CW
and keys
Sto
p
/Exit ke
y
Black Start ke
y
Men
u
ke
y
O
K
ke
y
