III- 46
[ 7 ] Reassembling the Top Cover ASSY
(1) Put the end of the platen into the hole on the right hand side of the top cover.
Fig. 3.2-32 Reassembling the Top Cover ASSY (1)
(2) Put the other end of the platen into the hole on the left hand side.
Fig. 3.2-33 Reassembling the Top Cover ASSY (2)
Top cover
Platen ASSY
Top cover
Platen ASSY
Platen ASSY
