I- 1
CHAPTER I SPECIFICATIONS
1.1 MECHANICAL SPECIFICATIONS
1.1.1 External Appearance
[ 1 ] Dimensions (W x D x H) 170mm x 222mm x 147.5mm
[ 2 ] Weight Approx. 1.7kg (Machine proper only)
147.5mm 170mm
222mm
Fig. 1.1-1 External Appearance
1.1.2 Keyboard
[ 1 ] Number of function keys 3
[ 2 ] Key arrangement See Fig. 1.1-2.
Fig. 1.1-2 Key Arrangement
1.1.3 Display
[ 1 ] Display type LED 1 (ON/OFF: Green On/Off, Error: Red blinking
Cover open: Yellow On/Off,
Cooling: Yellow blinking)
CUT button
FEED button
POWER button
LED lamp
