BRP ROTAX 912 Series User Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
Figure 5.8
1
Dowel pins 6x20
ATTENTION
The sealing surface must be free from dirt and oil.
Step
Procedure
7
Clean both sealing surfaces with LOCTITE 7063 or equivalent cleaner.
8
Apply a thin layer of LOCTITE 5910 surface sealing compound to the
sealing surface of the gearbox housing.
9 Fit gearbox into position, carefully aligning crankshaft, dowels and
gears.
NOTE
Move the propeller shaft a little to allow the dog gear to engage.
ATTENTION
If excessive installation force is used, the bearing or vacuum pump gear can be
damaged.
Step
Procedure
10
Tap gently on the gearbox housing with a soft-faced hammer to position
the gearbox on the crankcase.
Effectivity: 912 Series
Rev. 0
05–50–00
Page 9
January 01 2020
