T401S Indicator User Instructions 49
8.3 Counting application supervisor menu
2. Press UNITS …
count is displayed. Use this to set the items relating to counting:
l Enable/Disable the ability to print the accumulated total (Prt tot).
l Key in a print format number for printing the total accumulated
information (tot FMt).
l Enable/Disable the ability to clear the total accumulation information
when the total is printed (clr tot).
l Reset the accumulator memory channel value to 0 (rESEt).
The following steps describe the procedure to set these items.
Print total
Count Print Total
3. From count, press SELECT …
Prt tot is displayed. This stands for print total.
4. Press SELECT …
oFF is displayed.
5. Press ZERO to keep the print total function disabled or press UNITS to toggle
to on and press ZERO to enable printing of the accumulated total …
Prt tot is displayed.
If enabled, during normal operation the user can press and hold PRINT
for three seconds and the selected total print format (see step 8 below)
will be sent out any port that is set up to print. The display will flash Prn-
tot.
Total format
Count Print Total Total Format
6. Press UNITS …
tot FMt is displayed. This stands for the total print format.
7. Press SELECT …
The current print format number is displayed with a flashing right-most
digit. (Default is format 8)
8. Press ZERO to accept the existing setting or key in a new format number and
press ZERO …
tot FMt is displayed.
To Next Page
