2.7.1 Position of safety installations
The figure below shows the position of the saety installations.
Fig.2: Safety installations
1
Main switch on the control cabinet of the Mass
preparation unit
2
Main switch on the control cabinet of the
cutting unit
3
Emergency stop button
4
Touch Panel (on/off)
5
Solenoid safety switch for protective hoods and
hoppers
Furher safety installations are installed at the 15l vessel
  please see the separate documentation
