Buhler SnackFix - Equalizing Roller EGW 180

Design and Function
Component Description
44 SnackFix  2016-08
4.2.4 Equalizing roller EGW 180
Fig. 11: Equalizing roller
1
Equalizing roller
2
Scraper
3
Hand crank of the lifting and lowering device
4
Gear motor
5
Side guiding
The equalizing roller is mounted on the transport belt.
The equalizing roller evens the surface of the mass slab and cali-
brates the slab height.
The height of the equalizing roller can be adjusted with a spindle.
The roller is driven by a gear motor which is operated by a frequency
controller. The rotational speed of the equalizing roller can be adjust-
ed at the control panel.
Scrapers clean the roller from mass particles.
Short description
1
2
4
1
3
