4.2 Component Description
4.2.1 15l vessel
Please see the separate documentation “BONAMAT” in
the documentation file for further information.
4.2.2 Pump
Please see the separate documentation“Pump” in the
documentation file for further information.
4.2.3 Mass preparation unit
Fig. 9: Mass preparation unit
1
40l hopper
2
Vibration feeder
3
Contimix
4
15l Vessel
5
Gear pump
6
Control cabinet
7
Control cabinet
8
Emergency-stop button
7
4
6
3
2
8
1
