Inputs / outputs
Overview of types
Setpoint input
Process value output
The setpoint input servec to enter the analog setpoint value via a standard signal
for the MFC.
The process value output exits the current flow rate as a standard signal.
NOTE As an option you can obtain the PC software "Mass Flow
Communicator", with which you can switch over the standard signal
for the setpoint input and the process value output between 0 - 5 V,
0 - 10 V, 0 - 20 mA and 4 - 20 mA (see Appendix C).
Type Setpoint
input
Process
value output
BUS
connection
LED Binary
inputs
Relay
outputs
8006 - X - 4 3 2
8626 X X - 4 3 2
8006 Bus - - X 4 3 2
8626 Bus - - X 4 3 2
8700 - X - 3 2 1
8710 X X - 3 2 1
8700 Bus - - X 3 2 1
8710 Bus - - X 3 2 1
8701 - X - 3 2 1
8711 X X - 3 2 1
8701 Bus - - X 3 2 1
8711 Bus - - X 3 2 1
8702 - X - 4 3 2
8712 X X - 4 3 2
8702 Bus - - X 4 3 2
8712 Bus - - X 4 3 2
8703 - - X 3 1 1
8713 - - X 3 1 1
8706 - X - 4 3 2
8716 X X - 4 3 2
8706 Bus - - X 4 3 2
8716 Bus - - X 4 3 2
