Start-up, operation
process controller Type 8693
X0 - Working point of the process controller
Operating point in rest state.
Factory setting: 0.0 %
+
-
X0 0.0%
X0 0.0%
INPUT
OK
*
Adjustment range:
0 – 100 %
Fig. 7: Operating structure P.CONTROL - X0
The "Process controller tables" appendix contains a table "Set parameters of the process controller" in which you
can enter your parameters.
FILTER - Filtering of the process actual value input
The filter is valid for all process actual value types and has a low pass behaviour (PT1).
Factory setting: 0
+
-
FILTER 0
FILTER 0
INPUT
OK
*
Adjustment range:
0 – 9
Fig. 8: Operating structure P.CONTROL - FILTER
Setting in 10 stages
Setting
Corresponds to
limit frequency (Hz)
Effect
0 10 Lowest filter effect
15
22
31
4 0.5
5 0.2
6 0.1
7 0.07
8 0.05
9 0.03 Largest filter effect
* If the sub-menu is left by pressing the selection key on the left (ESC), the value remains unchanged.
