44
Type 8692, 8693
english
Installation
4.3 Type 8693 - Designation of the multipole plugs and the contacts
Circular plug M12
4-pin
Circular plug M12
8-pin
1
2
3
4
Operating voltage
Output signals
to PLC
1
2
3
4
5
6
7
8
Process actual
value
1
2
3
4
Circular plug M8
4-pin
Switch
(behind the screw)
Fig. 3: Designation of the multipole plugs and contacts 8693
4.4 Connection of the Process Controller Type 8693
First connect the process controller as described in the chapter entitled “4.2 Connecting the Position Controller Type 8692”. →
4.4.1 Process Actual Value (circular plug M 8)
Input type* Pin Configuration Switch External circuit
4 – 20 mA
- internally supplied
1
2
3
4
+ 24 V transmitter supply
Output from transmitter
GND
Bridge after GND (GND from
3-wire transmitter)
Switch on
left
GND
1
2
3
4
Transmitter
I
4 – 20 mA
- externally sup-
plied
1
2
3
4
Not assigned
Process actual +
Not assigned
Process actual -
Switch on
right
2
4 GND
4 ... 20 mA
Frequency
- internally supplied
1
2
3
4
+ 24 V sensor supply
Clock input +
Clock input - (GND)
Not assigned
Switch on
left
1
2
3
+ 24 V
Clock +
Clock -
Frequency
- externally sup-
plied
1
2
3
4
Not assigned
Clock input +
Clock input -
Not assigned
Switch on
right
2
3 Clock -
Clock +
Pt 100
(see information
below)
1
2
3
4
Not assigned
Process actual 1 (current feed)
Process actual 2 (GND)
Process actual 3 (compensation)
Switch on
right
Pt 100
2
3
4
For reasons of wire compensation connect the Pt 100 sensor via 3 wires. Always bridge Pin 3 and Pin 4 on the sen-
sor.
When the power supply voltage is applied, the positioner is operating.
Now implement the required basic settings and activate automatic adjustment of the positioner as described in the chapter
→
entitled “Initial Start-up” or “Starting and Setting Up the Process Controller Type 8693”.
* Can be adjusted by software (see chapter entitled “Specifying the Basic Settings”)
