150
Type 8692, 8693
english
DeviceNet
9.2 Static Output Assemblies
Name Address of data attribute of the assemblies
for read access. Class, Instance, Attribute
Format of the
data attribute
INP (factory setting) 4, 21, 3 Byte 0: INP low
Byte 1: INP high
SP
4, 22, 3 Byte 0: SP low
Byte 1: SP high
The addresses indicated in the Static Output Assemblies table can be used to specify a path for the Consumed Connection
Path attribute of an I/O connection, whereby the attributes described in more detail in the following table can be transferred as
output process data via this I/O connection. Nevertheless, by using this address data, the attributes combined in the assemblies
can also be accessed acyclically via Explicit Messages .
Name Description of the output data attributes Attribute Address Class,
Instance, Attribute;
Data type, Length
INP
Nominal position
Set-point value of position controller as ‰. Value range 0–1000. In
"pure" position controller mode (P.CONTRL inactive) the transfer of the
nominal position INP is required; as a process controller (PCONTRL
active) the transfer of INP is not possible. If the value is too small or too
large, the last valid value is used and is indicated in ERR with HEX 14.
111, 1, 58;
UINT, 2 byte
SP *
Process set-point value
Set-point value of process controller in physical unit (as set in the menu
P.CO INP or P.CO SCAL), max. value range –999–9999, depending on
internal scaling.
If the value is too small or too large, the last valid value is used and is
indicated in ERR with HEX 15.
120, 1, 2;
INT, 2 byte
* relevant only for type 8693 and when process controller activated.
