Type 8692, 8693
english
Start-up, operation
process controller Type 8693
3.3 AUTOMATIC operating state
Bar running from left to right along the upper edge of the display.
Normal control mode is implemented and monitored in AUTOMATIC operating state.
3.3.1 Meaning of the keys
key Configuration* Description
Left selection key MENU Switch to the Configuration level (press for approx. 3 s)
Right selection key MANU Switch between the AUTOMATIC (AUTO) or MANUAL (MANU)
operating modes
Up arrow key
SP
POS
CMD
TEMP
PV
Switch between the displays
Down arrow key
CMD
TEMP
PV
SP
POS
3.3.2 Information on the Display
The following variables are indicated on the display for the process controller and it is possible to switch between them with the
arrow keys:
Representation of
value*
Value range / unit Description
POS XXX
0...100 % Display of actual position of the valve actuator
CMD XXX
0...100 % Display of nominal position of the valve actuator
TEMP XXX
-100 – 150 °C Internal temperature in the housing of the positioner
PV XXX
Depending on the signal
type
Process actual value
SP XXX
Depending on the signal
type
Process set-point value
* Displayed only when P.CONTROL auxiliary function activated
