Type 8692, 8693
english
Start-up, operation
process controller Type 8693
1 SAFETY INSTRUCTIONS
DANGER!
Danger – high pressure in the equipment!
There is a serious risk of injury when reaching into the equipment.
Before loosening the lines and valves, turn off the pressure and vent the lines.•
WARNING!
Danger - improper installation!
Improper installation may result in injuries as well as damage to the device and the area around it.
Fluid and electrical installations may be carried out by authorised technicians only and with the appropriate tools!•
Danger due to unintentional activation of the equipment!
Unintentional activation of the equipment during installation may result in injuries and damage.
Take appropriate measures to prevent the equipment from being unintentionally activated.•
2 STARTING UP AND SETTING UP THE PROCESS CONTROLLER
TYPE 8693
Before starting up the device, carry out the fluid and electrical installations as described in the chapter entitled →
“Installation”.
To set up the positioner as a process controller, it is first necessary to specify the basic functions of the position controller and
then supplement the auxiliary functions for the process control.
2.1 Description of the procedure
When the operating voltage has been switched on, the positioner is at the process operating level in the AUTOMATIC operat-
ing state.
To specify the basic settings, you must switch to the configuration level:
Hold down the left selection key (MENU) for approx. 3 seconds (wait for countdown on display).
→
Then the main menu is indicated on the display (MAIN).
Press the arrow keys to switch between the main menu options and select a menu option with the right selection key →
(ENTER/RUN).
Depending on the function, a menu sub-option or a selection screen is indicated on the display.
Press the arrow keys to switch between these sub-options and select the required settings. Press the right selection key
→
(SELEC/ENTER) to confirm the selection (the point after the selected parameter is now marked). Return to the main menu
by pressing the left selection key (EXIT).
To save the changed settings, you must leave the configuration level by pressing the left selection key (EXIT). →
You are back at the process operating level.
Only when you leave the configuration level by pressing the right selection key, are the changed parameters and settings
saved (“save EEPROM”).
