4 AUXILIARY FUNCTIONS FOR THE PROCESS CONTROLLER
In this chapter only those auxiliary functions are described which differ from the position controller Type 8692. All other auxil-
iary functions and their settings can be found in the chapters entitled "Start-up, operation of the position controller
Type 8692" - "Configuring the auxiliary functions".
4.1 Overview of the auxiliary functions
ENTER
CHARACT
EXIT
ADD.FUNCTION
Selection of the transfer characteristic between input
signal and stroke (correction characteristic)
CUTOFF
Sealing function for position controller
DIR.CMD
Effective sense of direction between input signal and
nominal position
DIR.ACT
Assignment of the aeration state of the drive chamber
to the actual position
SPLTRNG *
Signal split range; input signal as % for which the
valve runs through the entire stroke range.
X.LIMIT
Limit of the mechanical stroke range
X.TIME
Limiting the control speed
X.CONTROL
Parameterisation of the position controller
SECURITY
Code protection for settings
SAFEPOS
Input the safety position
SIG.ERROR
Configuration of signal level fault detection
BINARY. IN
Activation of the binary input
OUTPUT
Configuration of the outputs (option only)
CAL.USER
Calibration
SET.FACTORY
Reset to factory settings
SER. I / O
Configuration of serial interface
EXTRAS
Set colours on display
SERVICE
For internal use only
P.CONTROL
Parameterisation of the PID process controller
Fig. 20: Overview - auxiliary functions 8693
* SPLTRNG auxiliary function can only be selected if P.CONTROL auxiliary function is inactive.
