42
Type 8692, 8693
english
Installation
4 ELECTRICAL CONNECTION - MULTIPOLE PLUG MODEL
DANGER!
Danger - electrical voltage in the equipment!
There is a serious risk of injury when reaching into the equipment.
Before starting work, always switch off the power supply and safeguard to prevent re-activation!•
WARNING!
Danger - improper installation!
Improper installation may result in injuries as well as damage to the device and the area around it.
Fluid and electrical installations may be carried out by authorized technicians only and with the appropriate tools!•
Danger due to unintentional activation of the equipment!
Unintentional activation of the equipment during installation may result in injuries and damage.
Take appropriate measures to prevent the equipment from being unintentionally activated.•
Using the 4 - 20 mA nominal value input
If the operating voltage of one positioner device fails in a series connection of several devices, the input of the failed
positioner device becomes highly resistive. As a result, the 4 - 20 mA standard signal fails. In this case please contact
Bürkert Service directly.
If PROFIBUS DP or DeviceNet:The designation of the multipole plugs and sockets and the contacts can be found
in the respective chapters.
4.1 Type 8692 - Designation of the multipole plugs and the contacts
Circular plug M12
4-pin
Circular plug M12
8-pin
1
2
3
4
Operating voltageOutput signals to PLC
1
2
3
4
5
6
7
8
Fig. 2: Designation of the multipole plugs and contacts 8692
