153
Type 8692, 8693
english
DeviceNet
11.3 Offline Parameterisation of the Device
When a device has been inserted into the DeviceNet configuration of RSNetWorx, the device can be parameterised offline.
Fig. 8 indicates how, for example, an input assembly which deviates from the factory setting (input process data can be transferred
via I/O connection) can be selected. However, ensure that the length of the process data during a subsequent configuration of
the DeviceNet master/scanner is adjusted accordingly (see chapter entitled Configuration Example 2).
All parameter changes implemented offline must become operative for the real device at a later date by a download
process.
Fig. 8: Screenshot - DeviceNet - Fig. 2
